Architecture Diagram

System Architecture

This section describes the high-level architecture of the Hepek Web3 MQTT Master platform.

• Dockerized microservices for API, MQTT, and blockchain logic
• MQTT for real-time meter data
• Web3 for blockchain integration
• Modbus for industrial meter data
• Encrypted secrets for security
